Knife adjustment

Adjust knives aromatically, positional accuracy within 0. 5mm

Height adjustment

Auto-adjust the height of roller,furniture carton slotting is available, the height is not limited

Feeding mode

Automatic feeding

Feeding plate structure

Use vacuum suction with front edge plate feeding structure

Slotting speed

Max 120 sheets/min, linear speed 1.6 m/s

Slotting Depth

315mm（315-420mm canbe customized)

Slotting indentation

Combine slotting and indentation into one machine

Easy operation

Touch screen input, saving time and sheets, reset to zero automatically

Power dissipation

Lower power dissipation, the average only 2KW,energy conservation and environment protection

Transmission material

Transmission gear use 40Cr alloy steel, excellent abrasion resistance

Cardboard Min. Size

665mm*400mm

Cardboard Max. Size

Automatic feeding: Below 2500mm*1350mm

Rated Power

About 16 kw, AC380±10%, 50 ~ 60 Hz

Machine Size

5780mm（L） * 1800mm(W) * 1850mm (H)

Weight:

About 7500kgs
